GRYPHON CALLISTO 2200
Amplificador integrado a transistores.
Entradas analógicas RCA y XLR..
Potencia de salida: 2 x 200 W a 8 ohmios.
PRODUCTO DE OCASION.
PERFECTO ESTADO. GARANTIA 1 AÑO.
Gryphon Callisto
2200 Integrated
Amplifier
True Dual Mono configuration
Infrared remote control.
Flash memory upgrades via
PC
Zero negative feedback.
Microprocessor-controlled
passive volume potentiometer.
Dual Mono Holmgren toroidal
transformer.
Extensive mechanical decou-
pling.
Minimal internal wiring.
Ultra-short signal path.
Non-magnetic, non-resonant
aluminum cover.
Military spec. double-sided
printed circuit boards.
PCB-mounted sockets elimi-
nate wiring and shorten signal
path.
Gold-plated Swiss Neutric
XLR sockets for one balanced
source.
Exclusive custom Gryphon
gold-plated phono sockets
with Teflon insulation for 4
inputs.
Fixed-level AV input for inte-
gration with surround pream-
plifier.
Vacuum Fluorescent Display
with 2 lines and 50
85696
Technical Specifications:
Frequency Response :
20Hz – 20kHz, +0.0 / -0.2dB.
0.25 – 250kHz, +0 / -3dB.
Input impedance : 10K
Av Input impedance: 47K
THD+N : 1kHz < 0.05%, 20kHz <
0.25%.
Signal to Noise
< -100dB “A-weighted”
Gain : 38dB.
Input sensivity : 700mV.
Input sensivity AV-input : 1V.
Output Power :
Both channels driven
2 x 200Watt in 8 Ohm.
2 x 400Watt in 4 Ohm.
2 x 600Watt in 2 Ohm.
Output voltage :
RMS : 40 V
Peak to Peak : 113 V
Output impedance : 0.028 Ohm
Power consumption :
Idle : 200Watt.
Max : 1400Watt.
Dimensions:
H. 175 mm W. 480 mm.
D. 420 mm.
Weight
Shipping weight 27 kgs.
Unit only 24 kgs.
Features, functions
